Iris Automated Border Control E-gates: High-Security & Liveness Detection

Product Details

Place of Origin: China

Brand Name: HOMSH

Certification: ISO9001

Model Number: G32e

Payment & Shipping Terms

Minimum Order Quantity: 1

Price: Negotiated

Delivery Time: 5-8 work day

Payment Terms: L/C, T/T

Get Best Price
Highlight:

2000 People Iris Border Control

,

Iris Border Control G32e

,

2000 People automated border control

Equipment Size:
260mm*206mm*105mm
Display Screen:
8 Inch 1280*800
Iris Camera:
Dual Lens,20x Optical Zoom
Structured Light Camera:
Depth Image: 640x400@30FPS / Color Image 1280*720@7FPS
Recognition Distance:
35cm~100cm
Native Support For Iris Capacity:
2000 People
Focus Method:
Auto Focus
Infrared Lighting:
850nm Infrared LED Lights On Both Sides
Product Name:
Iris Automated Border Control E-gates
Operating Temperature:
0~55°C
Security:
High
Speed:
High
Equipment Size:
260mm*206mm*105mm
Display Screen:
8 Inch 1280*800
Iris Camera:
Dual Lens,20x Optical Zoom
Structured Light Camera:
Depth Image: 640x400@30FPS / Color Image 1280*720@7FPS
Recognition Distance:
35cm~100cm
Native Support For Iris Capacity:
2000 People
Focus Method:
Auto Focus
Infrared Lighting:
850nm Infrared LED Lights On Both Sides
Product Name:
Iris Automated Border Control E-gates
Operating Temperature:
0~55°C
Security:
High
Speed:
High
Iris Automated Border Control E-gates: High-Security & Liveness Detection

High-Security Iris Automated Border Control E-gates Automated Border Control System

Description



The iris channel machine is based on iris recognition technology. When performing iris identity verification, it compares the iris data of the person being verified with the iris data of the entire database to accurately determine the identity information of the person being verified. During the iris identity verification, if the person being verified is found to be a key focus person, the system will automatically alarm and record the alarm information data. Equipped with automatic zoom technology, the equipment can quickly and accurately identify any position within the range of 35cm~100cm. It is suitable for deployment at important checkpoints such as highway checkpoints, border inspections, customs, high-speed rail stations, and airports for identity verification and traffic control.



Features



1. Equipped with Rainbow Technology's independent iris recognition algorithm Phaselis™ and the world's first iris recognition hard-core dedicated smart chip Qianxin™; (invention patent number ZL 201410430535.2)

2. The equipment complies with the requirements of the "Technical Requirements for Iris Collection Equipment Used in Criminal Investigation Services" (used for the construction of the iris database of the ten-million-level criminal special subsystem);

3. With liveness detection, it can prevent prosthetic attacks in the form of iris photos and iris videos;

4. Adopt automatic zoom technology to realize rapid iris recognition in the range of 35~100cm;

5. Average recognition time <2s;

6. Adopt high-performance 6-core ARM chip and integrate Linux system;

7. Using professional ID three-dimensional modeling, industrial design, strict high and low temperature environment test, stable and reliable performance;

8. Adopt industrial-grade 8-inch IPS LCD screen, professional UI design and intelligent voice prompts, display the human eye frame, and facilitate user calibration;

9. The device supports data network upload, continuous transmission when the network is disconnected, and supports receiving data sent by the B/S cloud platform;

10. Support access to tens of millions of iris recognition databases for accurate and fast identity confirmation;



Specifications



Equipment size

260mm*206mm*105mm

display screen

8 inch 1280*800

iris camera

Dual lens, 20x optical zoom

Structured Light Camera

Depth image: 640x400@30FPS / Color image: 1280*720@7FPS

recognition distance

35cm~100cm

Native support for iris capacity

2000 people

focus method

auto focus

Infrared lighting

850nm infrared LED lights on both sides

Infrared Safety Standard

Conforms to the American standard ANSI RP-27.1-96 Conforms to the highest European standard IEC/EN62471

iris image format

BMP

Iris image size

The monocular iris image is 640 pixels wide and 480 pixels high

Iris Image Quality

Comply with ISO/IEC-19794-6:2011 and GB/T 26237.6-2014 standards

Meet the requirements of "Technical Requirements for Iris Collection Equipment Used in Criminal Investigation Business" (used for the construction of iris database of tens of millions of criminal special subsystems)

communication method

TCP/IP, RS-485, Wiegand

Access control interface

Door lock/door sensor/exit switch

Operating temperature

0~55℃

power supply

24VDC, 5A





Applicable field



G32e is widely suitable for road checkpoints, border inspections, customs, airports, high-speed rail stations, prisons, coal mines and other scenarios.
