MD30 Iris Recognition Module - 55g Lightweight Unit with 300mm~500mm Operating Distance

Product Overview

Core Functions and Technical Features

1. Dual-Lens Stitching & Full-Cycle Iris Recognition

      ● Dual-Lens Expands Recognition Range: Integrates 2 2-megapixel image sensors, and with dual-lens stitching technology, enables any single-eye/dual-eye recognition within a 300mm~500mm working distance, expanding the effective interaction range and adapting to user operation habits in more scenarios.

      ● Precise Capture & Alignment Assistance: Covers an imaging wavelength range of 700nm~900nm and supports video echo-assisted alignment to ensure the accuracy of iris capture; the generated iris features have "uniqueness + lifelong stability" and are highly anti-counterfeiting identifiers in the field of biometrics.

      ● Large-Capacity Storage & High-Speed Matching: Supports local storage of 10,000 iris templates, and the iris matching speed reaches 10,000 templates/second (USB real-time delivery), meeting the needs of identity management and rapid authentication in medium and large-scale scenarios.

2. High-Performance Imaging & Third-Generation Algorithm

      ● Imaging Specifications: Image resolution 640×480, pixel depth 8 bits/pixel, image frame rate 25 frames/second, spatial resolution >4.0 Lp/mm (>16 Pixels/mm), capturing iris texture details clearly.

      ● Ultra-Fast Authentication Experience: Adopts Phaseiris^TM third-generation iris recognition algorithm, with registration time ≤1 second and recognition time ≤1 second, achieving a False Acceptance Rate (FAR) of 10⁻⁷ and a False Rejection Rate (FRR) of 10⁻³, balancing efficiency and safety reliability.

      ● Video Output Capability: Supports a maximum 200M video output, providing expansion possibilities for scenarios such as visual identity authentication and system linkage.

3. Hardware Specifications & Environmental Adaptability

      ● Compact & Lightweight Design: Product dimensions 80mm×40mm×30mm, typical weight 55g, with a USB interface and power consumption of 5W, facilitating integration into various terminal devices and simplifying the hardware integration process.

      ● Wide-Range Environmental Tolerance:

               Operating illuminance: 0~6000 Lux, capable of stably capturing clear iris images in low-light or strong-light environments;

               Operating temperature: -10℃~55℃; Humidity adaptability: 0~93% RH, suitable for diverse deployment scenarios such as indoor, outdoor, high and low temperatures.

4. Standard Compliance & Cross-Platform Compatibility

      ● Safety & Technical Standards:

               Eye safety complies with IEC 62471 "Photobiological Safety of Lamps and Lamp Systems";

               Iris images comply with China's GB/T 33767.6-2018 "Iris Image Data" standard;

               Algorithm performance complies with China's GB/T 20979-2019 "Information Security Technology - Technical Requirements for Iris Recognition Systems".

      ● Cross-Platform SDK Support: Provides a matching SDK, compatible with Windows XP/7/8/10, Linux, Android and other systems, facilitating secondary development for different applications.

Typical Application Scenarios

      ● Access Control & Security Admission: Iris access control systems in enterprises, parks, office buildings (300-500mm working distance supports "stand-up" or "close-range" convenient recognition), ensuring physical space security.

      ● Smart Cabinets & Terminals: Iris safes, smart courier lockers (realizing cabinet permission management through iris authentication), or identity verification modules of VTMs (remote banking terminals).

      ● Portable Collection & Authentication: Portable iris collectors (used in scenarios such as floating population management, event identity verification, etc.) to achieve flexible mobile identity authentication.

Why Choose MD30 Iris Recognition Module?

      1. Dual-Lens Technological Breakthrough: Dual-lens stitching expands the recognition range and depth-of-field, improving user interaction convenience.

      2. Large Capacity + High-Speed Matching: 10,000 template storage + 10,000 templates/second matching speed, adapting to medium and large-scale scenarios.

      3. Precision of Third-Generation Algorithm: Phaseiris™ algorithm achieves FAR 10⁻⁷/FRR 10⁻³, ensuring reliable authentication security.

      4. Easy Integration + Cross-Platform: USB interface + multi-system SDK, simplifying terminal device integration and secondary development.

      5. Wide-Range Environmental Adaptation: Wide temperature, illuminance, and humidity ranges meet the deployment needs of complex scenarios.

      As a professional enterprise in the biometric sector, Wuhan Homsh Technology drives secure authentication through technological innovation. Leveraging proprietary core algorithms, end-to-end technical capabilities, and high-precision hardware expertise, we provide professional support for our full range of biometric products, including iris recognition and vein recognition.

      We cater to the needs of global industries like finance and security, offering technical consultation, custom development, and round-the-clock after-sales support. We look forward to partnering with global counterparts to build a secure authentication ecosystem via biometric technology and empower industrial digital upgrading.
