Product Details
Place of Origin: China
Brand Name: HOMSH
Certification: ISO9001
Model Number: i10-100a
Payment & Shipping Terms
Minimum Order Quantity: 1
Price: Negotiated
Delivery Time: 8 work day
Payment Terms: T/T
User Data Capacity: |
64 Users |
Password Length: |
6-13 Digits |
Recognition Time: |
1 Second |
Collection Distance: |
20-35cm |
Infrared Auxiliary Lighting: |
810nm Wave LED × 2 |
Power: |
4W |
Operating Temperature: |
-20°C To 80°C |
Operating Humidity: |
20% To 80% |
Operating Illuminance: |
0 To 5000LUX |
Door Thickness Range: |
40-120mm |
User Data Capacity: |
64 Users |
Password Length: |
6-13 Digits |
Recognition Time: |
1 Second |
Collection Distance: |
20-35cm |
Infrared Auxiliary Lighting: |
810nm Wave LED × 2 |
Power: |
4W |
Operating Temperature: |
-20°C To 80°C |
Operating Humidity: |
20% To 80% |
Operating Illuminance: |
0 To 5000LUX |
Door Thickness Range: |
40-120mm |
Description
Introducing our advanced access control system featuring iris recognition technology for secure and convenient authentication. This system supports multiple access methods, including iris scanning, password entry, and mechanical unlocking, ensuring versatility for various users.
Crafted with a robust combination of main body strength alloy and 304 stainless steel, our system is suitable for doors with thickness ranging from 40 to 120mm. It can be easily installed for left or right inward and outward openings, providing flexibility for different settings.
Product characteristics
Iris recognition:
Using independent intellectual property iris recognition technology, safe and convenient.
Identification time ; 1s, FAR; 10-7
Unlocking method:
Iris recognition unlocking, virtual cipher unlocking, key unlocking
Lock core:
Super Class B anti-theft lock core
Lock Body:
High strength zinc alloy shell, SUS304 stainless steel lock body,
Military free handle design, more durable
Power Supply:
18200mAh lithium battery, Micro USB emergency power supply
Intelligent alarm:
Automatic alarm for low voltage/failure/violent damage
Specifications
| Attribute | Value |
|---|---|
| Opening Mechanism | Iris, Password, Mechanical Unlocking |
| Lock Body Material | Main body strength alloy, 304 stainless steel |
| Door Thickness Range | 40-120mm |
| Installation Method | Left/Right Inward Opening, Left/Right Outward Opening |
| User Data Capacity | 64 users |
| Password Length | 6-13 digits |
| Collection Method | Non-contact, Automatic Trigger |
| Recognition Method | Any single eye |
| False Acceptance Rate (FAR) | 0.00001% |
| False Rejection Rate (FRR) | 0.1% |
| Recognition Time | 1 second |
| Collection Distance | 20-35cm |
| Infrared Auxiliary Lighting | 810nm Wave LED × 2 |
| Infrared Light Safety | Complies with the highest US standard ANSI RP-27.1-96, Complies with the highest European standard IEC/EN 62471 |
| Alignment Assistance Mode | 2.4-inch LCD screen, 320×240 pixels |
| Battery Specifications | 3.7V, 18200mAh Lithium Battery |
| Power | ≤4W |
| Operating Temperature | -20°C to 80°C |
| Operating Humidity | 20% to 80% |
| Operating Illuminance | 0 to 5000LUX |
Application
The product uses the iris recognition technology opened by the brush eye, and realizes the WAN network control function, realizes the centralized management of the iris collection, door lock management, permission allocation, and real-time monitoring to improve security, especially for cross-regional management in chain hotels, large groups, banks, security and other fields.
